BSD Camera AI Solution MDVR

MDVR Blind Spot Detection Camera Active Safety Assisted Driving System BSD Camera blocked alarm Blind Spot Detection(Optional)



  • Item NO:

    TS-317C10-U7-AHD
  • Order(MOQ):

    5
  • Product Origin:

    Shenzhen
Product Detail
Product Detail

BSD Camera

Illustration

Model:TS-317C10

Technical Parameters

Item

Parameter

Sensor

JX-H65,1/4'',120W CMOS Sensor

Pixel Size

3.75um*3.75um

Lens type

4G

Length

3.6mm

Iris

F2.4

Lens Connector Type

M12*P0.5

FOV(Field of View)

D=112° H=92° V=51°


Color

Resolution

default1280*720P(1280*960 max)

Output Signal

Analog HD

Video Format

default PAL

Frame Rate

25FPS

Power Voltage

VCC12V

Power Current

47--105mA(±10%)

Power Consumption

0.56--1.26W(±10%)

Waterproof Level

IP67

Work Temperature

-20°-- +60°

Stored Temperature

-25°-- +80°

Aviation Cable

0.57m
